G20CM34

Gas Generator Sets

The G20CM34 is a spark ignited engine operating according to the lean burn combustion system. The use of a pre-chamber operated by means of a spark plug enables a combustion at high efficiency and low emissions. The cylinder-pressure based engine management of the G20CM34 enables engine operation at the efficiency optimum. The single-stage turbocharged, charge air cooled 20 cylinder engine reaches an electrical efficiency of up to 48 % and an overall efficiency of up to 93 %. Two charge air coolers allow a maximum utilization of the available displacement. A two-circuit cooling water system ensures flexibility. With a high temperature (HT) and a low temperature (LT) stage each, individual configurations for high altitudes of installation, high intake air temperatures, and natural gases with varying methane numbers are available. Depending on the requirements, these configurations can be optimized for purely electric power generation and combined heat and power. Stable engine operation at varying natural gas qualities is ensured by means of cylinder-specific knocking detection and continuous NOx control. An optimum material design (as e.g. the flow-optimized gas supply in the cylinder head) ensures a long service life of the components. Low fuel and lubricating oil consumption as well as low maintenance effort cater for high availability and cost efficiency of the engine.

Show
Continuous Rating 9830 / 10300 ekW @ 0.8 pf
Fuel Type Natural Gas
Maximum Electrical Efficiency 48.90%
Frequency 50 / 60 Hz
Availability Contact Dealer
Request A Quote Rent a Machine
Download Brochure
G20CM34
Request A Quote

OVERVIEW

10500 KW Gas Generator Set

FEATURES & BENEFITS

Genset Details

Spark ignited lean burn natural gas engineElectric power output with 10300 / 9830 ekW at 50 / 60 Hz applicationMedium-speed engine concept with high efficiency up to 48.9... Read more

Fuel Flexibility

Capability for operation with various gas qualitiesVariable configuration for natural gas with diverse methan number Read more

Customization

Withstand the most challenging conditions and is thus offering a wide range of applicationsMaximized benefits thanks to individual, tailor-made adjustments and extensions... Read more

Modular scope of supply

The Caterpillar Standard Scope of Supply ensures maximum safety, best performance and excellent service capability for your Power Plant with our Gensets. Operational reli... Read more

Gas Valve Unit

The GVU is a stand-alone auxiliary and regulates the gas supply under all required conditions for engine operation. It is designed for natural gas operation and is theref... Read more

Cooling water and lube oil combined module

The combined module includes the main components of the cooling water system and the lube oil system and is located in the power house. It provides the engine with a suff... Read more

World Wide Product Support

Training Center: Get the most out of your engine while we are focusing on your individual requirements. We provide a customized engine training for customer and dealer pe... Read more

SPECIFICATIONS FOR G20CM34

Collapse All
Generator Set Specifications
Continuous Rating 9830 / 10300 ekW @ 0.8 pf
Fuel Type Natural Gas
Maximum Electrical Efficiency 48.90%
Frequency 50 / 60 Hz
RPM 750/720
Frequency 50/60 Hz
Engine Specifications
Engine Model G20CM34
Displacement 762.6 l
Aspiration Turbocharged and Aftercooled
Bore 340 mm
Stroke 420 mm
Generator Set Dimensions
Length 14280 mm
Width 3910 mm
Height 5390 mm
Dry Weight - Genset 164000 kg
