C280-8

Commercial Propulsion Engines

Building on the durability and reliability of the C280 engine platform, Caterpillar is pleased to offer the C280-8 engine line. The core components are the same as the existing C280, including the latest in EUI fuel system capabilities and state-of-the-art ADEM™ A3 Electronic Control Unit (ECU) features. Caterpillar® products continue to deliver more available power while delivering outstanding fuel efficiency. You can also count on long maintenance intervals and worldwide Caterpillar parts and service availability. All C280-8 engines ratings are IMO II compliant. Engines rated at 2460 bkW and 2710 bkW, with aftertreatment, are IMO III/EPA Tier 4 compliant.

Show
Power Range 3084-4023 bhp (2300-3000 bkW)
Speed Range 900 - 1000 rpm
Emissions IMO II, IMO III/EPA Tier 4
Aspiration TA
Availability Contact Dealer
Request A Quote Request Rental Quote
Download Brochure
C280-8
Request A Quote

OVERVIEW

Building on the durability and reliability of the C280 engine platform, Caterpillar is pleased to offer the EPA Tier 2 compliant C280 engine line. The core components are the same as the existing C280, including the latest in EUI fuel system capabilities and state-of-the-art ADEM™ A3 Electronic Control Unit (ECU) features. Caterpillar® products continue to deliver more available power while delivering outstanding fuel efficiency. You can also count on long maintenance intervals and worldwide Caterpillar parts and service availability.

FEATURES & BENEFITS

A3 ECU

• CAN J1939 data link • Waterproof connectors • Maintenance-free • Backup ECU for redundant governing Read more

Electronic Advantages:

• Load feedback • Programmable droop • Adjustable gain • Adjustable fuel/air ratio control • Histograms of engine operation • Cat Messenger display presents diagnostics a... Read more

Data Advantages through J1939 Link:

• Engine speed • Boost pressure • Throttle position • Fuel consumption rate • Inlet manifold temperature • Diagnostic codes and events • Configuration • Desired engine sp... Read more

Customer Interface Panel

• Interfaces with standard Cat® Marine Monitoring System (PLC in Price List) • Provides visual indication of ECU functionality • Accepts 4 — 20 mA or PWM remote throttle... Read more

Electronic Unit Injectors

• “Drop-in” installation • No threaded fuel connections • High pressure inside injector only • Does not require double wall fuel lines or leak collection device • Injecto... Read more

SPECIFICATIONS FOR C280-8

Collapse All
Power Rating
Power Range 3084-4023 bhp (2300-3000 bkW)
Engine Specifications
Speed Range 900 - 1000 rpm
Emissions IMO II, IMO III/EPA Tier 4
Aspiration TA
Bore 280 mm
Stroke 300 mm
Displacement 148 l
Rotation from Flywheel End Counterclockwise or clockwise
Configuration In-line 8, 4-Stroke-Cycle Diesel
Dimensions & Weights
Height 2642 mm
Dry Weight 19000 kg
Width 1803 mm
Length 4953 mm
